Technical Specs

Dimensions30mm (h) X 45mm (w) X 15mm (d)
Weight25g excluding aerial
Temperature-20°C to +60°C transit
Humidity0 – 80% non – condensing
MountingAny orientation
WarrantyPlease refer to our terms and conditions.
Power Requirement9.0 v – 30.0 v (DC)
Current ConsumptionQuiescent = 15 mA
Signalling = 200 mA
Radio PathGPRS
Aerial50 ohm (nominal) on MMCX socket
Operation MethodStore and forward
CIE Interconnections1 Digital Input, 1 Digital Output, Analogue (Dial Capture)
RCT Protocols Fast Format, SIA & Contact ID
User Serviceable PartsThere are no serviceable parts within the MiniAir
EnvironmentalClass II
Applicable StandardsSuitable for use in alarm systems complying to: EN50136-1:2012 SP1
ATS Classification: EN50136-1-1:1998 ATS 1/Grade 2
